fisher 10
PDF technical datta →
ESPECIFICATIONS
TECHNICAL ESPECIFICATIONS
- Max. Lift beam elevation: 63 in. (160 cm)
- Min. Elevation (Standard Head): 13.75 in. (35 cm)
- Min. Elevation (Low Level Head): 3.375 in. (9 cm)
- Vertical beam travel: 47 in. (119 cm)
- Lift beam capacity: 500 pds. (227 kg)
- Lifts per system charge: 7
- Length: 55.25 in. (140 cm)
- Width - (wheels in): 26.625 in. (160 cm)
- Width - (wheels out): 32 in. (68 cm)
- Height (operating): 38.5 in. (98 cm)
- Height (folded): 25 in. (64 cm)
- Min. turn radius (round steering): 22 in. (56 cm)
- Min. turn radius (conventional steering): 44 in. (112 cm)
- Battery box (BRE): 10 in. (25,4 cm) L x 7in. (17,8 cm) W x 6,75 in. (17,1 cm) H
- Max. Dolly load capacity: 1200 Pds. (544 kg.)
- Carrying weigth: 435 Pds. (197 kg.)
- Crated size: L 59 in. (150 cm) L x 31 in. (79 cm) W x 34 in. (86 cm) H
- Crated weigth: 928 pds. (421 kg) Standared package.
fisher 11
PDF technical datta →
ESPECIFICATIONS
TECHNICAL ESPECIFICATIONS
- Max. Lift beam elevation: 51.125 in. (130 cm)
- Min. Elevation (Standard Head): 13.75 in. (34.925 cm)
- Min. Elevation (Low Level Head): 3 in. (7.62 cm)
- Vertical beam travel: 33.375 in. (84.773 cm)
- Lift beam capacity: 200 pds. (90.72 kg)
- Length: 40 in. (102 cm)
- Width - (wheels in): 20.375 in. (51.753 cm)
- Width - (wheels out): 25.75 in. (65.405 cm)
- Height (operating): 39.625 in. (100.648 cm)
- Height (folded): 23.125 in. (58.738 cm)
- Min. turn radius (round steering): 16.188 in. (41.116 cm)
- Min. turn radius (conventional steering): 33.5 in. (85.09 cm)
- Battery box (BRE): 10 in. (25,4 cm) L x 7in. (17,8 cm) W x 6,75 in. (17,1 cm) H
- Carring weight: 316 Pds. B (143 kg)
- Max. Dolly load capacity: 900 pds. (408.23 kg)
- Crated size: 59 in. L x 31 in. W x 34 in. H
- Crated weigth: 775 pds. (351,5 kg) Standared package.
Magnum
especificaciones
TECHNICAL ESPECIFICATIONS
- a completely redesigned multi-functional turnstile
- a new, ergonomic and ultra-stable seat mount
- a new surface with scratch-resistant HART-COAT® and NUCOTEC® technology
- patented column-plate system
- use of high-strength materials on extremely stressed components (e.g. turnstile)
- 40% lighter platforms with anti-slip coating
- a new ergonomic telescopic handlebar with backlash-free connection to the dolly
- extra wide Studio tires with smoother running (optional)
- completely new position-faithful turnstile brake
- a revised electronic unit
- a completely new Kirin-Duo-Jib-System
- a new motor unit
- new dolly designand much more
Albatros
especificaciones
TECHNICAL ESPECIFICATIONS
- Min Length(A): 96cm
- Max. Length(B): 110cm
- Width(C): 52cm
- Width(D): 62cm
- Heigh(E): 35cm
- Heigh/F): 116cm
- Travel (G): 81
- Turn Radius ( R) 0-00
- Power Supply: 220V-110V/ 50Hz-60Hz
- Usable track gaube: 62cm
- Lifting capacity: 60kg
- Min. working (P): 90bar
- Max. working (P): 190bar
- Max. arm lifts: 9
- Weight: 147kg
Superfalcon
Tecnichal data →
especificaciones
TECHNICAL ESPECIFICATIONS
- Max. Length (A): 45.6 in – 116 cm
- Min. Width (B): 20.4 in – 52 cm
- Max. Width (C): 34.6 in – 88 cm
- Min. Height (D): 16.9 in – 43 cm
- Max. Height (E): 44.4 in – 113 cm
- Arm Travel (F): 27,5 in – 70 cm
- Crab : ✓
- Round : ✓
- Conventional : ✓
- Usable track gauge: 24.4 in – 62 cm
- Lifting Capacity: 131 lbs – 60 kg
- Precharge pressure : 90 bar
- Max. Working P: 180 bar
- Max. Arm lifts: 6
- Weight: 328 lbs – 149 kg
- Power Supply: 220V / 110V
- Battery powered : x
big wheels dolly / sprinter dolly
technical datta →
especificaciones
TECHNICAL ESPECIFICATIONS
- Standard plataform
- 2 running boards (left/right) (item no. 2900-100, 2900-120)
- Pneumatic wheels (item no. 2904-0 set)
- Track wheel set in hard case (item no. 2950-500)
- Pushbar and steering rod (item no. 2900-200, 2900-250)
